Acoustical Ceiling Panel - Eclipse™ ClimaPlus™ | USG Boral

Eclipse™ ClimaPlus™

Eclipse™ ClimaPlus™ Acoustical Ceiling Panels are built with a non-directional pattern to ensure a consistent appearance.

Especially designed with Superior Performance to withstand mould and mildew; these sag resistant, noise reducing panels are optimal for schools, hotels, lobbies, general office and conference areas and transportation terminals.

Features and Benefits

  • Elegant, fine-textured visual
  • Excellent noise reduction of up to .70 NRC
  • Optional Firecode® formulation
  • Available in Optimised Recycled Content formulations to help maximize LEED recycle content contribution.
  • ClimaPlus™  30-year lifetime system warranty to withstand conditions of up to 99% relative humidity without visible sag when used with DONN® Brand Suspension System
Physical Properties
  • Substrate: Mineral Fiber
  • Edge Profile: Square Edge, Shadowline Tapered, Fineline, BESK (Concealed)
  • Panel Thickness: 19mm
  • Panel Size: 600 x 600mm, 600 x 1200mm, 300 x 300mm
  • CAC: up to 40
  • Light Reflectance: .86
  • NRC: up to 0.7
  • Recycled Content: up to 50%
Applications
  • Offices
  • Conference Areas
  • Healthcare
  • Retail  Stores
